Inputs

Shaft - Inputs

Label Symbol Tooltip, note, formula
C.S. diameter D1 Connection side end-shaft diameter.
C.S. extension L1 Connection side end-shaft extension.
O.C.S. diameter D2 Opposite connection side end-shaft diameter.
O.C.S. extension L2 Opposite connection side end-shaft extension.
