Intersect
Extract curves resulting from the intersection of the sketch plane with selected parts or surfaces.
Create Intersection Curves
-
On the Sketch ribbon, select the
Intersect tool.
- On the toolbar, select Parts to choose parts to intersect with the sketch plane, or select Surfaces to choose surfaces to intersect with the sketch plane.
-
Select part(s) or surface(s) that intersect with the sketch plane to create
intersection curves.
The intersection curves appear as a dotted red line or curve, and can interact with your new sketch.
- Right-click and mouse through the check mark to exit, or double-right-click.
