Reference System Catalog

The Reference system catalog button appears only when a product is selected in the tree. The user defined values in Reference system catalog are used as input for Calculate inertia on given axis after calculate.

The tasks that can be carried out in the Reference system catalog options are:

• Add new Reference system catalog
  • Reference system name
  • Origin (X, Y, Z)
  • Plane (X, Y, Z)
  • Axis (X, Y, Z)
  • Notes
• Delete Reference system catalog
• Enable changes
• Save changes
• Undo Changes
• Export data as XSLX Report
• Show/Reset column filter
