terminate

A terminate pseudostate causes the state chart to terminate all execution.

Entering a terminate pseudostate implies that the execution of this state machine is terminated. The state machine does not exit any states nor does it perform any exit actions other than those associated with the transition leading to the terminate.

Icon

terminateblock

Color

Background: Reserved.

Foreground: Specifies the color of the icon.

Name: Specifies a name for the state.

Example

See Examples > State Charts > Terminate001.
