When solving an implicit equation, you can use the Newton Raphson solver or a custom solver. You can also set the error tolerance, maximum iteration count, perturbation, and relaxation parameters. After you choose the options you want, you can start the simulation.

To solve an implicit equation, enter the options in System > System Properties > Implicit Solver dialog.

**Error Tolerance:** Specifies the maximum allowable
difference in total error between two successive iterations. A total error is
computed as the sum of individual errors squared, where the error signal is the
input signal to a constraint block. Newton-Raphson ceases iterating when the
difference in total error between two successive iterations becomes less than
the tolerance.

**Use** **Error Tolerance** in conjunction with
**Max Iteration Count** to control the time spent converging. The larger the
tolerance, the quicker and less accurate the solution. The default is
0.0001.

**Max Iteration Count:** Specifies the number of
iterations the solver performs while attempting to meet the error tolerance
criterion. One iteration of the solver has many simulation runs to obtain the
local n-dimensional surface and run downhill one step. The default is 10.

**None:** When you’re not solving an implicit equation,
activate **None**.

**Newton-Raphson:** Newton-Raphson is a singular value
decomposition-based solver (SVD) that performs static optimization at each time
step. Embed derives an *n*-dimensional slope by numerically perturbing the
unknown outputs and observing the effects on the constraints. Embed uses the
slope matrix to compute values for the unknown blocks that drive the constraints
to a minimum.

Specifically, Newton-Raphson forms a Jacobian matrix of the partial derivatives of each unknown block on each constraint block by numerically adding a small offset (perturbing) for each unknown and seeing how it affects each constraint input. If an unknown block has no effect on a constraint block, the value at that element in the Jacobian is 0. The unknown block outputs are adjusted by the current error vector (vector of constraint inputs squared) divided by the Jacobian matrix. This is calculated using SVD. The unknown block updates are scaled by the Relaxation parameter. You should start with 1 and reduce if nonlinearities result in numerical instability. The perturbation value is the small offset used to calculate the Jacobian. It should be about 1% of the value of the smallest unknown. If it is too small (< max unknown*1e-13) then its effect can be lost and the unknown block will not factor into the Jacobian. The Error Tolerance is the sum of squares of all constraint inputs.

Newton-Raphson is particularly useful for solving static equations in the presence of concurrent dynamics.

**Perturbation:** Indicates the value by which the
unknown blocks are numerically perturbed to evaluate the Jacobean (matrix of
first partials). Each element of the Jacobean is a ratio of constraint change
with respect to block perturbation value applied to the unknown blocks. The
perturbation value should be at least one order of magnitude less than the
unknown initial value, but greater than 1e-12 of the initial value for the
unknowns. The default is 1e-007.

**Relaxation:** Attenuates the iteration update value to
attain convergence for equations that prove difficult to converge. As a side
effect, it slows the convergence process because it forces the iteration to take
smaller steps. The typical range is from slightly greater than 0 – 2.
Select values less than 1 for systems that appear to be unstable. The default is
1.

**Suppress Convergence Warnings:** If you’re solving for
a set of roots that are equidistant from 0, you must initialize the unknown
block to a value other than 0 to force the equations to converge. To suppress
the convergence warnings when solving an implicit system with nonlinear
dynamics, activate Suppress Convergence Warnings.

**User Defined:** When User Defined is activated, Embed
uses **VSOLVER.DLL** in your current directory to solve the equation. For
information on creating a custom solver, see Creating custom implicit
solvers.
