Block Category: Boolean, Fixed Point

Inputs: Real, complex, or fixed-point (scaled_int) scalars, or vectors or matrices.

Description: The or block generates the bitwise OR of 2 – 256 scalar input signals. The output of the or block is TRUE when at least one of the inputs is TRUE. When all the inputs are FALSE, the output is FALSE.

If you right-click the or block, the Boolean block menu appears allowing you to assign a different function to the block.
